Bevel Right Angle Gearboxes
Z Sizes 12-75 ZL Sizes 331 - 434 Amazing size to power ratio, with silent operation and efficient performance standard features of the STM Gearboxes range.
Downloads (1) Not sure which one? Call 0800 147 847
Overview
STM small right angle gearboxes
Z & ZL Series
- Z Sizes 12-75
- ZL Sizes 331 - 434
Amazing size to power ratio, with silent operation and efficient performance standard features of the STM Gearboxes range.
EQM Industrial supply STM Gearboxes New Zealand-wide. Contact Us for information on products and system designs.
Why STM Standard?
- Modular design
- Wide range of sizes and ratios
- Universal & standard mounting
- Patented input coupling design
- Full range of accessories
- Superior gear componentry
- Suitable for small medium workloads
- Interchangeable with other brands
- Your choice of colour
- Combinations for high ratios
- Torque limiters
- Epoxy or colour coated options
Suitable for
- Wide range of food processing systems
- Driving conveyor systems
- Mixers and agitator processes
- Mobile plant equipment
- Materials handling
- Any automation
Specifications
| Series | Size | Torque (Nm) | Shaft (mm) | Alternative Shaft (mm) |
|---|---|---|---|---|
| Z Series | 12 | 12 | 12 | - |
| 19 | 19 | 19 | 14 | |
| 24 | 24 | 24 | 19 | |
| 32 | 32 | 32 | 24 | |
| 38 | 38 | 38 | 28 | |
| 42 | 42 | 42 | 32 | |
| 55 | 55 | 55 | 42 | |
| 75 | 75 | 75 | 55 | |
| ZL Series | 331 | 8 | 8 | - |
| 332 | 15 | 15 | - | |
| 333 | 20 | 20 | - | |
| 334 | 25 | 25 | - | |
| 432 | 14 | 14 | - | |
| 433 | 19 | 19 | - | |
| 434 | 24 | 24 | - |
PDFHave any questions?
Talk to the EQM team about sizing, fit or system design.
